Software tools and models

Become a high-skilled geospatial professional

The Department of Water Resources has developed and/or co-developed a number of models and demos to retrieve and handle environmental information from earth observation data.

SCOPE

SCOPE (Soil Canopy Observation, Photochemistry and Energy fluxes) is a simulation model for quantitative remote sensing of vegetation and land surface processes. It describes radiative and non-radiative energy fluxes in the soil-vegetation-atmosphere system.

Read more
ILWIS/GEONETCast

The GEONETCast Toolbox is a plug-in for ILWIS, offering utilities that facilitate easy import of various satellite and environmental data / products that are disseminated via GEONETCast, into a common GIS environment.

Read more
iAqueduct

iAqueduct aims to close the gap between satellite observation of the global water cycle and the need for local information for sustainable water resource management, by converting coarse resolution data into fine scale water information.

Read more
SPART

SPART (Soil-Plant-Atmosphere Radiative Transfer) is a simulation model for soil-vegetation-atmosphere systems. The model uses three computationally efficient RTMs for soil (BSM), vegetation canopies (PROSAIL) and atmosphere (SMAC), respectively.

Read more
2SeaColor

2SeaColor is a two-stream remote sensing model for water quality mapping developed at the Department of Water Resources.

Read more
STEMMUS

STEMMUS (Simultaneous Transfer of Energy, Mass and Momentum in Unsaturated Soil) is a 1D numerical solver taking into account soil water movement, soil air flow, soil heat flow, and root water uptake processes.

Read more

Earth Observation Models

  • SCOPE

    SCOPE (Soil Canopy Observation, Photochemistry and Energy fluxes) is a simulation model for quantitative remote sensing of vegetation and land surface processes. It describes radiative and non-radiative energy fluxes in the soil-vegetation-atmosphere system. More information about Scope.

  • SPART

    SPART (Soil-Plant-Atmosphere Radiative Transfer) is a simulation model for soil-vegetation-atmosphere systems. The model uses three computationally efficient RTMs for soil (BSM), vegetation canopies (PROSAIL) and atmosphere (SMAC), respectively. It simulates remote sensing signals both above vegetation canopies and top of the atmosphere, and supports quantitative remote sensing of vegetation. It is written in Matlab and has been translated to Python. More information can be found here: https://github.com/peiqiyang/SPART

  • STEMMUS

    STEMMUS (Simultaneous Transfer of Energy, Mass and Momentum in Unsaturated Soil) is a 1D numerical solver taking into account soil water movement, soil air flow, soil heat flow, and root water uptake processes. Further information, including model description, downloads, instructions for use, publications and points of contact can be found here: https://www.itc.nl/about-itc/organization/scientific-departments/water-resources/stemmus/

  • 2SeaColor

    2SeaColor is a two-stream remote sensing model for water quality mapping developed at the Dept of Water Resources. More information can be found here: https://research.utwente.nl/en/publications/two-stream-remote-sensing-model-for-water-quality-mapping-2seacol and the model can be downloaded here: https://github.com/suhybsalama/2SeaColor.

  • DATTUTDUT

    DATTUTDUT (Deriving Atmosphere Turbulent Transport Useful To Dummies Using Temperature) is a very simple fully automated model for remote sensing-based estimates of turbulent heat and water vapor fluxes and daily actual evapotranspiration rates utilizing only a temperature image. More information is available from https://research.utwente.nl/en/publications/utility-of-an-automated-thermal-based-approach-for-monitoring-eva-2. The model can be downloaded from Github: https://github.com/ClaireBrenner/DATTUTDUT and is implemented as a plugin in QGIS: https://plugins.qgis.org/plugins/qwatermodel/

Toolboxes

  • ILWIS/GEONETCast and toolbox plugins

    The GEONETCast Toolbox is a plug-in for ILWIS, offering utilities that facilitate easy import of various satellite and environmental data / products that are disseminated via GEONETCast, into a common GIS environment. ILWIS 3 and various toolbox plugins (e.g., GEONETCAST, Sentinel EO4SD, FAO-Frame and TripleSensor toolboxes) can be downloaded from: https://www.itc.nl/about-itc/organization/scientific-departments/water-resources/geonetcast/

  • MAJISYS (time series toolbox)

    MAJISYS is a free and open source web-based tool for the management, analysis and visualization of time series. MAJISYS is the result of a development cooperation under the IWRAP programme between the University of Twente (Faculty ITC, departments GIP and WRS), Deltares and Upande. More information: https://www.itc.nl/about-itc/organization/scientific-departments/water-resources/majisys/

  • iAqueduct (downscaling toolbox)

    iAqueduct aims to close the gap between satellite observation of the global water cycle and the need for local information for sustainable water resource management, by converting coarse resolution data into fine scale water information. An iAqueduct online toolbox to downscale Sentinel SM product at 1km to 16cm using UAV data can be accessed here: http://iaqueduct.itc.utwente.nl/iaqueduct/. The overall project for which iAqueduct is developed and project partners are described here: https://www.costharmonious.eu/iaqueduct-water-jpi/

Other websites with useful tools/code developed by WRS researchers
